High-end digital-to-analog converter

The M8x DAC by Musical Fidelity represents a continuation of the brand’s long-standing commitment to high-end digital-to-analog conversion. Since the 1990s, Musical Fidelity has been at the forefront of DAC development, and the M8x DAC builds upon this legacy by offering world-class audio performance suited for today’s digital sources. Whether streaming music or listening from a PC, the M8x DAC transforms digital signals into rich, analogue sound with Musical Fidelity’s signature blend of clarity and musicality.

At its core, the M8x DAC utilizes dual ES9038Q2M Sabre DAC chips in a dual differential, dual mono configuration. This setup allows it to support a wide range of digital formats, including PCM files up to 768kHz, native DSD512, and MQA via USB and SPDIF. Key technologies include a proprietary clock system with jitter rates under 100 femtoseconds, a Time Domain Jitter Eliminator, and advanced upsampling and reclocking capabilities. The system is powered by 16-core XMOS and CPLD MAX II processors, enabling seamless digital filtering and MQA decoding. One standout feature is its discrete and fully balanced output stage. Unlike designs using integrated circuits,

Musical Fidelity has opted for traditional discrete components—transistors, resistors, and capacitors—which contribute to superior sonic performance, serviceability, and longevity. This fully balanced design enhances noise rejection and dynamic range by processing both positive and negative audio signals independently. The oversampling bypass mode further boosts performance by reducing internal noise and allowing ultra-high-resolution signals to be processed with minimal interference. Equally impressive is the M8x DAC’s built-in headphone amplifier. It’s a discrete, fully differential, Class A design with immense power reserves—up to 3900mW into 8 ohms for balanced headphones, compared to 2000mW unbalanced. It supports low-impedance headphones down to 8 ohms and operates in Class A up to full power for headphones 30 ohms and above. Balanced headphones benefit from a true balanced circuit, not just a balanced connector, resulting in better dynamics and reduced distortion.

Internally, the DAC is powered by an ultra-quiet Super Silent Power Transformer and separate analog/digital power supplies. EMI filtering, DC blocking, and passive regulation ensure clean power delivery, especially critical in a fully balanced setup. Mechanically, the chassis is milled from thick aluminium, acting as a vibration-dampening Faraday cage for electromagnetic protection. Eschewing flashy displays, the minimalist design focuses all engineering efforts on sonic performance. In sum, the M8x DAC is a no-compromise, high-resolution DAC and headphone amp that exemplifies Musical Fidelity’s engineering excellence and dedication to pure, powerful, and emotionally engaging sound.
