Eversolo DAC-Z10
Digital-to-analog converter and preamplifier
Eversolo DAC-Z10 is a digital-to-analog converter, which is capable of handling digital signals and converting them to analog, in very high quality.
Eversolo DAC-Z10 highlights
- Dual AKM DAC chipset
- Large touch screen
- Balanced outputs
- AES/EBU, I2S and S/PDIF connections
- Clock outputs
But the DAC-Z10 is not just a DAC - it is a huge upgrade of the digital platform in a Hi-Fi system, where the desire is uncompromising performance. Built on a fully isolated architecture with three separate power supplies, it delivers an extremely low noise floor with a revealing level of detail. The brain of the DAC-Z10 is, among other things, based on a dual chipset from Japanese AKM, where each channel is processed by an AK4191 and an AK4499 respectively. Combined with a temperature-controlled OCXO clock, every bit is processed at the highest level with PLL correction that virtually eliminates any risk of time shifts. If you dare to improve performance even further, it is actually also possible to connect an external clock generator.
| Measurements | 36,5 x 8,8 x 31 cm |
| Input, optical (TosLink) | 2 |
| Input, coaxial (S/Pdif) | 2 |
| Input, I2S | 1 |
| Input, Clock Sync | Yes |
| Input, USB | 1, USB (for firmware updates and service only) |
| Input, AES/EBU | 1 |
| Input, Stereo RCA | 1 |
| Input, Stereo XLR | 1 |
| Input, HDMI | 1 |
| Output, Stereo RCA | 1 |
| Output, Stereo XLR | 1 |
| Output, Headphone | 1/4" TRS |
| 12v. trigger input | Yes |
| 12v. trigger output | Yes |
| Pre-out (stereo) | Yes |
| Audio decoding | DSD64 / 2.8 MHz, DSD128 / 5.6 MHz, DSD256 / 11.2 MHz, DSD512 / 22.5 MHz, DXD |
| Supported sample rates, kHz | 44.1, 48, 88.2, 96, 176.4, 192, 352, 384, 768 |
| Supported bit depth | 16 bit, 24 bit, 32 bit |
| Audio chipset (DAC) | 2 x AKM AK4191EQ + 2 x AK4499EXEQ |
| In the box | Remote control, Power cable, Users guide |
| Other included accessories | USB cable, trigger cable, USB stick, polishing cloth |
| User manual available in | English |
| Power consumption | 32 watts |
| Made in | China |
